Connect and share with up to 40 Wireless Devices
Less Shadow and Glare
Optional Multi-pen and Touch Interactivity
Robust and Dust Resistant
Great Connectivity
Low Cost of Ownership
Connect and share : With up to 40 Wireless Devices with The NEC Image Express Utility (Windows & MAC) as Well as Wireless Image Utility (IOS & Android) Software.
Less Shadow and Glare : Not Standing in The Light Beam Gives You More Space to Engage with Your Audience When Presenting.
Optional Multi-pen and Touch Interactivity : With Auto-Calibration on any Kind of Surface.
Robust and Dust Resistant : Thanks to Sealed DLP Light Engine.
Great Connectivity : Due to Numerous Analog and Digital Connection Terminals as well as Network Capability.
Low Cost of Ownership : Up to 8000h Lamp Life, Low Power Consumption.
Projector Information :-
Product Name : M333XS
Product Group : Professional Short-Throw Projector
Order Code : 60003974
Image :-
Projection Technology : 1-chip DLP™ Technology
Native Resolution : 1024 x 768 (XGA)
Aspect Ratio : 4:3
Contrast Ratio : 10000:1
Brightness : 3300 ANSI Lumen (approx. 75% in Eco Mode)
Lamp : 270 W AC (162 W AC Eco Mode)
Lamp Life [hrs] : 8000 Eco / 5500 Normal / 3500 High Bright Mode
Lens : F= 2.4, f= 6.5 mm
Projection Angle [°] : 40.7 - 40.9
Projection Factor : 0.56 : 1
Projection Distance [m] : 0.68 – 1.76
Screen Size (diagonal) [cm] / [inch] : 152.4 / 60" - 381 / 150"
Zoom : Digital Zoom
Focus Adjustment : Manual
Supported Resolutions : 1920 x 1080 (HDTV 1080i/60, HDTV 1080i/50), 1680 x 1050 (WSXGA+), 1600 x 1200 (UXGA), 1600 x 900 (WXGA++), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1366 x 768 (WXGA), 1360 x 768 (WXGA), 1280 x 1024 (Maximum resolution of digital input), 1280 x 1024 (SXGA), 1280 x 1024 (MAC 23"), 1280 x 960 (SXGA), 1280 x 800 (WXGA), 1280 x 768 (WXGA), 1280 x 720 (HDTV 720p), 1152 x 870 (MAC 21"), 1152 x 864 (XGA), 1024 x 768 (XGA), 832 x 624 (MAC 16"), 800 x 600 (SVGA), 720 x 576 SDTV 480p/480i, 720 x 576 (DVD progressive), 720 x 480 SDTV 576p/576i, 720 x 480 (SDTV 480p), 640 x 480 (VGA/MAC 13").
Frequency : Horizontal 15–100 kHz (RGB: 24 kHz– 100 kHz), Vertical 50 – 120 Hz
Connectivity :-
RGB (analog) Input : 1 x Mini D-sub 15-pin, compatible to component (YPbPr)
RGB (analog) Output : 1 x Mini D-sub 15 pin
Digital : Input (2 x HDMI™ (Deep Color, Lip sync))
Video : Input (1 x RCA)
Audio Input : 1 x 3.5 mm Stereo Mini Jack; 1 x RCA Stereo
Audio Output : 1 x 3.5 mm Stereo Mini Jack (variable)
Microphone : Input (1 x 3.5 mm Monaural Mini Jack (Dynamic mic / Condenser mic))
Control : Input (1 x D-Sub 9 pin (RS-232) (male))
LAN : 1 x RJ45, Optional WLAN
USB : 1 x Type A (USB 2.0 high speed), 1 x Type B
3D Sync : Output (1 x Mini DIN 3pin)
Video Signals : NTSC, NTSC 4.43, PAL, PAL-M, PAL60, SECAM
Remote Control :-
Aspect Ratio, Audio Control, Auto Adjust, Automatic Picture Adjustment, AV Mute, Digital Zoom, Freeze, Help
Eco Mode, ID set, Keystone Correction, Lamp Mode Control, Magnify-function, Optional Presentation and
Mouse Control, Picture Adjust, Source Select
Electrical :-
Power Supply : 100-240 Volt AC, 50-60 Hz
Power Consumption [W] : 278 (Normal) / 246 (Eco) / 2.9 (Network Stand-by) / 0.4 (Stand-by); 335 (High Bright)
Mechanical :-
Dimensions : (Width x Height x Depth) [mm] : 368 x 97 x 286 (without lens and feet)
Weight [kg] : 3.7
Fan Noise [dB (A)] : 30 / 30 / 36 (ECO / Normal / High Bright)
Environmental Conditions :-
Operating Temperature [°C] : 5 to 40
Operating Humidity [%] : 20 to 80
Storage Temperature [°C] : -10 to 50
Storage Humidity [%] : 20 to 80
Ergonomics :-
Safety and Ergonomics : CE; EAC; Gost-R; RoHS; TUEV Type Approved
Speakers [W] : 1 x 20 (mono)
Additional Features :-
Special Characteristics 3D ready, Ambient Light Sensor, Auto Eco Mode, Auto Power-ON Function, Automatic and manual Keystone Correction (V= +/-30°), Carbon Savings Meter, Colour Management, Constant Brightness Mode, Content Transmission via Network, Crestron RoomView, DICOM Simulation, Direct Power-Off Function, Full 3D DLP® LINK support, High Altitude Mode, Kensington security slot, Keypad Lock, Magnify, NaViSet Administrator 2, Off-Timer, Optional User Logo, Optional WLAN, OSD with 29 languages, Password Security System, Quick Start, Remote control and administration via LAN and RS232, Security Bar, Simple Access Point, USB Viewer for JPEG, Virtual Remote for direct PC control, Wall Colour Correction.
Green Features :-
Energy Efficiency : 75 % AV mute function, Auto ECO Mode, ECO scheduler, Green one touch ECO and AV mute button,
ImageCare® Technology, Intelligent Power Management, Longer lamp life, Reduced power consumption.
Only 0.4W stand-by, Software scheduling.
Ecological Materials : 100% recyclable packaging, Downloadable manuals, ECO packaging.
Ecological Standards : ErP compliant, RoHs compliant, WEEE.
Warranty :-
Projectors : 3 Years pan-European service
Light Source : 6 months, max. 1000 hrs
Shipping Content :-
IR Remote Control (RD-469E), Lens Cap, Mini D-SUB Signal Cable, Power Cord (3 m), Quick Setup Guide,
Security Sticker, Users Manual on CD-ROM.
Optional Accessories :-
Cable Cover (NP05CV), DisplayNote, DLP-Link 3D Glasses (NP02GL, VolfoniFit), Interactive Unit (NP03Wi),
Lamp (NP30LP), Wall Mount Kit (NP05WK), Wireless LAN module (NP05LM).
Connect and share : With up to 40 Wireless Devices with The NEC Image Express Utility (Windows & MAC) as Well as Wireless Image Utility (IOS & Android) Software.
Less Shadow and Glare : Not Standing in The Light Beam Gives You More Space to Engage with Your Audience When Presenting.
Optional Multi-pen and Touch Interactivity : With Auto-Calibration on any Kind of Surface.
Robust and Dust Resistant : Thanks to Sealed DLP Light Engine.
Great Connectivity : Due to Numerous Analog and Digital Connection Terminals as well as Network Capability.
Low Cost of Ownership : Up to 8000h Lamp Life, Low Power Consumption.
Projector Information :-
Product Name : M333XS
Product Group : Professional Short-Throw Projector
Order Code : 60003974
Image :-
Projection Technology : 1-chip DLP™ Technology
Native Resolution : 1024 x 768 (XGA)
Aspect Ratio : 4:3
Contrast Ratio : 10000:1
Brightness : 3300 ANSI Lumen (approx. 75% in Eco Mode)
Lamp : 270 W AC (162 W AC Eco Mode)
Lamp Life [hrs] : 8000 Eco / 5500 Normal / 3500 High Bright Mode
Lens : F= 2.4, f= 6.5 mm
Projection Angle [°] : 40.7 - 40.9
Projection Factor : 0.56 : 1
Projection Distance [m] : 0.68 – 1.76
Screen Size (diagonal) [cm] / [inch] : 152.4 / 60" - 381 / 150"
Zoom : Digital Zoom
Focus Adjustment : Manual
Supported Resolutions : 1920 x 1080 (HDTV 1080i/60, HDTV 1080i/50), 1680 x 1050 (WSXGA+), 1600 x 1200 (UXGA), 1600 x 900 (WXGA++), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1366 x 768 (WXGA), 1360 x 768 (WXGA), 1280 x 1024 (Maximum resolution of digital input), 1280 x 1024 (SXGA), 1280 x 1024 (MAC 23"), 1280 x 960 (SXGA), 1280 x 800 (WXGA), 1280 x 768 (WXGA), 1280 x 720 (HDTV 720p), 1152 x 870 (MAC 21"), 1152 x 864 (XGA), 1024 x 768 (XGA), 832 x 624 (MAC 16"), 800 x 600 (SVGA), 720 x 576 SDTV 480p/480i, 720 x 576 (DVD progressive), 720 x 480 SDTV 576p/576i, 720 x 480 (SDTV 480p), 640 x 480 (VGA/MAC 13").
Frequency : Horizontal 15–100 kHz (RGB: 24 kHz– 100 kHz), Vertical 50 – 120 Hz
Connectivity :-
RGB (analog) Input : 1 x Mini D-sub 15-pin, compatible to component (YPbPr)
RGB (analog) Output : 1 x Mini D-sub 15 pin
Digital : Input (2 x HDMI™ (Deep Color, Lip sync))
Video : Input (1 x RCA)
Audio Input : 1 x 3.5 mm Stereo Mini Jack; 1 x RCA Stereo
Audio Output : 1 x 3.5 mm Stereo Mini Jack (variable)
Microphone : Input (1 x 3.5 mm Monaural Mini Jack (Dynamic mic / Condenser mic))
Control : Input (1 x D-Sub 9 pin (RS-232) (male))
LAN : 1 x RJ45, Optional WLAN
USB : 1 x Type A (USB 2.0 high speed), 1 x Type B
3D Sync : Output (1 x Mini DIN 3pin)
Video Signals : NTSC, NTSC 4.43, PAL, PAL-M, PAL60, SECAM
Remote Control :-
Aspect Ratio, Audio Control, Auto Adjust, Automatic Picture Adjustment, AV Mute, Digital Zoom, Freeze, Help
Eco Mode, ID set, Keystone Correction, Lamp Mode Control, Magnify-function, Optional Presentation and
Mouse Control, Picture Adjust, Source Select
Electrical :-
Power Supply : 100-240 Volt AC, 50-60 Hz
Power Consumption [W] : 278 (Normal) / 246 (Eco) / 2.9 (Network Stand-by) / 0.4 (Stand-by); 335 (High Bright)
Mechanical :-
Dimensions : (Width x Height x Depth) [mm] : 368 x 97 x 286 (without lens and feet)
Weight [kg] : 3.7
Fan Noise [dB (A)] : 30 / 30 / 36 (ECO / Normal / High Bright)
Environmental Conditions :-
Operating Temperature [°C] : 5 to 40
Operating Humidity [%] : 20 to 80
Storage Temperature [°C] : -10 to 50
Storage Humidity [%] : 20 to 80
Ergonomics :-
Safety and Ergonomics : CE; EAC; Gost-R; RoHS; TUEV Type Approved
Speakers [W] : 1 x 20 (mono)
Additional Features :-
Special Characteristics 3D ready, Ambient Light Sensor, Auto Eco Mode, Auto Power-ON Function, Automatic and manual Keystone Correction (V= +/-30°), Carbon Savings Meter, Colour Management, Constant Brightness Mode, Content Transmission via Network, Crestron RoomView, DICOM Simulation, Direct Power-Off Function, Full 3D DLP® LINK support, High Altitude Mode, Kensington security slot, Keypad Lock, Magnify, NaViSet Administrator 2, Off-Timer, Optional User Logo, Optional WLAN, OSD with 29 languages, Password Security System, Quick Start, Remote control and administration via LAN and RS232, Security Bar, Simple Access Point, USB Viewer for JPEG, Virtual Remote for direct PC control, Wall Colour Correction.
Green Features :-
Energy Efficiency : 75 % AV mute function, Auto ECO Mode, ECO scheduler, Green one touch ECO and AV mute button,
ImageCare® Technology, Intelligent Power Management, Longer lamp life, Reduced power consumption.
Only 0.4W stand-by, Software scheduling.
Ecological Materials : 100% recyclable packaging, Downloadable manuals, ECO packaging.
Ecological Standards : ErP compliant, RoHs compliant, WEEE.
Warranty :-
Projectors : 3 Years pan-European service
Light Source : 6 months, max. 1000 hrs
Shipping Content :-
IR Remote Control (RD-469E), Lens Cap, Mini D-SUB Signal Cable, Power Cord (3 m), Quick Setup Guide,
Security Sticker, Users Manual on CD-ROM.
Optional Accessories :-
Cable Cover (NP05CV), DisplayNote, DLP-Link 3D Glasses (NP02GL, VolfoniFit), Interactive Unit (NP03Wi),
Lamp (NP30LP), Wall Mount Kit (NP05WK), Wireless LAN module (NP05LM).
| Main-Сategory | Projectors |
|---|---|
| Brand | NEC |
| Product Model | M333XS.. |
| Warranty | 3 Years warranty |
