NEC Laser Projector With 1-chip DLP™ Technology P502HL

Projector Information :-
Projector Name : P502HL
Projector Group : Laser Projector
Order Code : 60003694
Image :-
Projection Technology : 1-chip DLP™ Technology
Native Resolution : 1920 x 1080 (Full HD)
Aspect Ratio : 16:9
Contrast Ratio : 15000:1
Brightness : 5000 ANSI Lumen
Lamp : Laser Light Source
Lamp Life [hrs] : 20000
Lens : F= 2–2.5, f= 18.2–31.1 mm
Lens shift : H:±0.25, V:+0.62,-0
Lens Offset [%] : 0-62
Keystone correction : +/- 25° Manual Horizontal / +/- 30° Manual Vertical
Projection Factor : 1.24 – 2.1 : 1
Projection Distance [m] : 0.8 – 14.2
Screen Size (diagonal) [cm] /[inch] : Maximum: 762 / 300", Minimum: 76.2 / 30"
Zoom : Manual, x1.7
Focus Adjustment : Manual
Supported Resolutions : 1920 x 1200 (Maximum resolution of analog input), 1920 x 1080 (Maximum resolution of digital input)
Frequency : Horizontal 15–100 kHz (RGB: 24 kHz), Vertical: 50 – 120 Hz
Connectivity :-
RGB (Analog) : Input ( 1 x Mini D-sub 15 pin )
                         Output ( 1 x Mini D-sub 15 pin )
Digital : Input ( 1 x HDBaseT, 2 x HDMI™ supporting HDCP )
Video : Input ( 1 x RCA )
Audio : Input ( 1 x 3.5 mm Stereo Mini Jack for Computer analog, 1 x RCA Stereo for Video, 2 x HDMI audio )
            Output ( 1 x 3.5 mm Stereo Mini Jack (variable))
Control : Input ( 1 x D-Sub 9 pin (RS-232) (male) )
LAN : 1 x RJ45, Optional WLAN
USB : 1 x Type B (for Service), 2 x Type A (USB 2.0 high speed)
3D Sync : Output ( 1 x Mini DIN 3pin )
Video Signals : NTSC 3.58, NTSC 4.43, PAL, PAL-M, PAL-N, PAL60, SECAM
Remote Control :-
Aspect Ratio, Audio Control, Auto Adjust, Eco Mode Control, Freeze-function, Help-function, ID set, Keystone Correction,
Magnify-function, Page (up, down), Picture Adjust, Picture Mute, Power (On-OFF), Presentation and Mouse Control,
Select (Up, Down, Left, Right), Source Select
Electrical :-
Power Supply : 100-240 V AC, 50 - 60 Hz
Power Consumption [W] : 442 (High Bright) / 347 (Eco) / 2 (Network Stand-by) / 0.3 (Stand-by)
Mechanical :-
Dimensions (W × H × D) [mm] : 469 × 137 × 365 (Without Lens and Feet)
Weight [kg] : 8.8
Fan Noise [dB (A)] : 31 / 39 (Eco / Normal)
Environmental Conditions :-
Operating Temperature : [°C] 5 to 40
Operating Humidity [%] : 20 to 80
Storage Temperature [°C] : -10 to 50
Storage Humidity [%] : 20 to 80
Ergonomics :-
Safety and Ergonomics : CE; ErP, RoHS, TUEV Type Approved
Speakers [W] : 1 x 20 (mono)
Additional Features :-
Special Characteristics 3D Ready, Auto Power ON/OFF, Carbon Savings Meter, Constant Brightness Mode,
Control ID Function,DICOM Simulation, Direct Power-Off Function, Geometric Correction by Software,
Help Function, HTTP Browser Control, Kensington Security Slot, Keypad Lock, Light Source Adjustment,
Magnify, Manual Wall ,Color Correction, Miracast Connectivity, Mouse Control with USB Display,
MultiPresenter Function,NaViSet, Administrator 2, Off-Timer, Optional User Logo, OSD with 27 languages,
Password Security System , Plug & Play W-LAN Option, Quick Start, Source Select with Beep Function,
Test Pattern, Timer-Function, Unique Power Saving Functions, USB Display Including Audio, USB Viewer,
Virtual Remote for Direct PC Control
Green Features :-
Ecological Materials Downloadable Manuals, ECO Packaging
Ecological Standards ErP Compliant, RoHs Compliant
Warranty :-
Projectors 3 Years Pan-European Service
Light Source 3 Years or 10000h (Whatever Comes First)
Shipping Content :-
IR Remote Control (RD-472E), Mini D-SUB Signal Cable (1.8 m), Power Cord (1.8 m),
Projector, Quick Setup Guide, Security Sticker, Users Manual, Utility Software
Optional Accessories :-
Cable Cover (NP08CV), DLP-Link 3D Glasses (Volfoni-Fit), Free Wireless Image Utility App, Universal Ceiling Mounts (PJ01UCM),
Wireless LAN module (NP05LM2, NP05LM4, NP05LM5), XpanD 3D Glasses (X105-RFX2), XpanD 3D RF Emitter (AD025-RF-X1)
